Item                                                                Data
Span(wide)of the canopy :                                             6M
Height of the canapy roof :                                             3.8M
Height of the canopy brim :                                            20'C
Slope of the canopy top :                                                2.5M
Length interval :                                                                3M
Longest pole :                                                                   3.5M
Maximum length of the canopy :                                    No limitation
 Minimum length of the canopy :                                    6M
Section of main pipe :                                                      84X48X3MM
Wind resistance of the canopy :                                     80KM/H(8grade)
Materials of main frame/                                                  High Strength Aluminum Alloy or Aluminum Steel
supporting frame :
Wind load :                                                                         0.3KG/M
Canopy materails :                                                           Double Faces PVC Composite Fiber Fabric;
                                                                                             Weight: 650G/M2;  Fire Resistance In Accordance  With
                                                                                             Germany Standard DIN4102B1,M2
